Sick Inductive Proximity Sensor IME08-03BPSZT0S
Original price was: $60.82.$55.29Current price is: $55.29.
SICK IME Series – Inductive Proximity Sensors for Industrial Automation
Comprehensive inductive proximity sensor portfolio from SICK. Available in M8 to M30 cylindrical housings with sensing ranges from 1.5 mm to 38 mm. Features DC 3-/4-wire or 2-wire configuration, PNP/NPN outputs, NO/NC functions, and IP67 protection. Nickel-plated brass housing with plastic sensing face. ASIC technology ensures precise switching points, high repeatability, and reliable operation. Shock and vibration resistant (30 g). Wide operating temperature (-25 °C to +75 °C). Connection options: M8/M12 connector, cable, or cable with connector. Safety variant (IME2S) available with two OSSD outputs, PL d / SIL 2 certified, for safe position monitoring without separate actuator. Ideal for presence detection, end position sensing, and positioning applications in machine tools, automotive, packaging, and logistics.
SICK IME Series – Inductive Proximity Sensors
| Feature / Specification | Details |
|---|---|
| Product Family | IME Inductive Proximity Sensors |
| Housing Sizes | M8 x 1, M12 x 1, M18 x 1, M30 x 1.5 |
| Sensing Ranges | 1.5 mm to 38 mm (depending on model) |
| Electrical Wiring | DC 3-wire / 4-wire / 2-wire |
| Switching Outputs | PNP or NPN |
| Output Functions | NO (Normally Open) / NC (Normally Closed) |
| Enclosure Rating | IP67 |
| Operating Temperature | -25 °C to +75 °C |
| Housing Material | Nickel-plated brass; plastic sensing face (PA 66) |
| Connection Types | M8/M12 connector, cable, or cable with connector |
| Special Features | ASIC technology, short-circuit protection, power-up pulse protection, high shock/vibration resistance (30 g) |
Typical Applications & Industries:
✓ Presence detection on conveying lines ✓ End position detection for lifting devices
✓ Positioning of transport trolleys and skids ✓ Machine tool and automotive manufacturing
✓ Food and beverage packaging ✓ Wind power plant safety monitoring
Detailed Description – SICK IME Inductive Proximity Sensor Portfolio
1. Series Overview – Precise Detection in Industrial Environments
The SICK IME series is a comprehensive family of inductive proximity sensors designed for precise, non-contact detection of metal objects in industrial automation. These sensors pack high technology into compact cylindrical housings, from M8 to M30 thread sizes . The integrated ASIC chip enables digital adjustment after manufacturing, ensuring highly precise switching points and very high repeatability across any number of production runs .
2. Rugged Construction for Demanding Conditions
IME sensors are completely encapsulated with hot-melt molding, which greatly increases shock and vibration resistance. The nickel-plated brass housing and IP67 enclosure rating make them suitable for harsh industrial environments including dust and moisture .
Key Durability Features:
✓ Shock and vibration resistance: 30 g, 11 ms / 10 Hz to 55 Hz, 1 mm
✓ Short-circuit protection – built-in
✓ Power-up pulse protection – prevents false switching during power-on
✓ Wide operating temperature: -25 °C to +75 °C
3. Technical Specifications
The IME series covers a broad range of sensing ranges and housing sizes to suit diverse applications :
| Parameter | Specification |
|---|---|
| Housing types | M8, M12, M18, M30 |
| Extended sensing ranges | 1.5 mm to 38 mm |
| Electrical configuration | DC 3-/4-wire, DC 2-wire |
| Enclosure rating | IP67 |
| Temperature range | -25 °C to +75 °C |
| Housing material | Nickel-plated brass |
| Sensing face | Plastic (PA 66) |
4. ASIC Technology – Precision and Reliability
The IME sensors feature SICK’s proven ASIC technology, which provides several key advantages:
✓ Digital adjustment after manufacturing for precise switching points
✓ High repeatability of switching values across production runs
✓ Reliable, stable processes even in demanding conditions
5. Connection Flexibility
IME sensors offer multiple connection options to suit different installation requirements :
M8 or M12 male connector – for quick, plug-and-play installation
Cable variants – flying leads for direct wiring
Cable with connector – combined solution for flexible routing
6. Safety-Related Variant – IME2S
The IME2S is a specialized inductive safety switch within the IME family, designed for safe position and area monitoring. Unlike standard IME sensors, the IME2S features two self-monitoring OSSD outputs and achieves PL d (EN ISO 13849) safety performance .
Key IME2S Features:
✓ Two OSSD safety outputs – for direct connection to safety controllers
✓ No separate actuator required – activated directly by metal machine parts
✓ Extended sensing range: 4 mm to 15 mm
✓ Safety rating: PL d, SIL 2
✓ Compact M12 to M30 housings
