SMC Cylinder CDQ2A32TF-30DMZ-XC35
原价为：$42.42。$38.89当前价格为：$38.89。
Main Product Series – Function & Application Comparison
| Cylinder Type | Operating Principle | Key Features | Typical Applications |
|---|---|---|---|
| Tie-Rod Cylinders | Linear motion via piston inside tie-rod reinforced tube | NFPA interchangeable, bore 32–300 mm, stroke up to 2,400 mm, air cushion standard | Heavy industry, mining, steel mills, assembly lines |
| Compact Cylinders | Short-stroke linear actuation | Space-saving, bore 12–100 mm, multiple mounting options, auto-switch ready | Pick-and-place, packaging, electronics assembly |
| Stainless Steel Cylinders | Corrosion-resistant linear actuation | SS304 body, FDA seals, NSF-H1 grease, IP67 rated, 4x wet environment life | Food processing, pharma, medical, cleanrooms |
| Rodless Cylinders | Magnetic or mechanical carriage coupling | No rod, bore 6–63 mm, stroke up to 1,000 mm, external guide required for load | Material handling, door openers, long-stroke transfer |
| Guided Cylinders | Integrated guide rods prevent rotation | Slide or ball bearing guide, bore 12–100 mm, non-rotating precision ±0.1°, high moment load | Press-fitting, lifting tables, positioning |
| Clamp Cylinders | Rotary + linear clamping motion | Bore 12–63 mm, 3x higher moment rating, built-in speed control option | Workpiece clamping, pallet fixing, welding fixtures |
| Lock Cylinders | Spring-applied brake engages on pressure drop | Bi-directional lock, bore 16–250 mm, intermediate stop, emergency drop prevention | Vertical lifts, suspended platforms, safety circuits |
Detailed Description – Industrial Grade Actuators
1. Tie-Rod Cylinders – CS1 / CS2 / CA2 / MB
Heavy-duty industrial cylinders. Aluminum die-cast body. Air cushioning standard.
CS1 – Max bore 300 mm. Max stroke 2,400 mm. Extreme duty.
CS2 – 50% weight reduction. Bore 125–320 mm. Dual air cushions.
CA2 – Bore 40–100 mm. Adjustable cushioning. RoHS.
MB – Bore 32–125 mm. Floating cushion seal. No piston bounce. High/low temp seals available.
2. Compact Cylinders – CQ2 / CM2 / CG
Low profile. High density. For tight spaces.
CQ2 – Bore 12–100 mm. Foot, flange, clevis, trunnion mounting. 4-side auto-switch mounting.
CM2 – Round body. Bore 12–63 mm. Single or double rod.
CG – Lightweight. Integrated switch grooves.
3. Stainless Steel Cylinders – HF2A-CG5
For food and pharma. Full stainless steel (SS304). No external threads or damping screws. Laser-printed labels.
Seals – FDA compliant FKW wipers.
Grease – NSF-H1 certified.
Lifespan – 4x longer than CG5-S in wet conditions.
Bore – 20–40 mm.
Stroke – 25–300 mm standard, 1,000 mm max.
Speed – 50–500 mm/s.
Damping – Adjustable pneumatic cushion. No manual screw.
4. Rodless Cylinders – CY3B / CY3R / MY1B
No piston rod. Long stroke. Short mounted length.
CY3B (Magnetic) – Bore 6–63 mm. Stroke 50–1,000 mm. External guide required. Industrial magnets.
CY3R – Direct mount. Resin lube retainers. Lower min pressure. 70% longer wear rings.
25A Variant – Cu and Zn free. For battery manufacturing.
MY1B (Mechanical) – Built-in guide. Higher load capacity. Pick-and-place ready.
5. Guided Cylinders – MGP / MGPM
Non-rotating. Handles moment loads.
MGP – Slide bearing. Bore 12–100 mm. Non-rotating precision ±0.1°.
MGPM – Ball bushing. Smoother motion. Higher lateral load.
MLGP – With spring lock. Drop prevention.
6. Clamp Cylinders – MK / CK
Rotary clamp + linear force. For automated workpiece fixing.
MK – Double acting. Bore 12–63 mm. 4-side auto-switch mounting. 3x higher moment rating.
CK – Standard, magnet, or strong magnet versions. Built-in speed control. No protruding valves.
CLK2 – With single-direction lock. Drop prevention on pressure loss.
7. Lock Cylinders – CL / CN Series
Spring-applied brake. Engages when air pressure drops. For vertical loads and safety circuits.
| Series | Bore (mm) | Lock Type | Application |
|---|---|---|---|
| CLJ2 / CLM2 / CLG1 | 16–40 | Bi-directional | Intermediate stop, emergency stop |
| CLQ | 20–100 | Single-direction | Drop prevention |
| MLGC | 20–40 | Bi-directional | Guided transfer + lock |
| CNG / CNS / CLS | 20–250 | Spring lock | Heavy-duty safety |
Naming Convention – SMC Cylinder Part Number
Example: CG5LN20-50
| Position | Meaning | Code Options |
|---|---|---|
| Series | Cylinder family | CG5, CS1, CQ2, CY3, MGP, MK, CL |
| Auto-switch | C = no switch, CD = with switch | C, CD |
| Bore | Inner diameter (mm) | 6, 10, 12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125, 140, 160, 180, 200, 250, 300 |
| Stroke | Travel length (mm) | 25, 50, 100, 150, 200, custom |
| Suffix | Options | Z (standard), X (special), -XC (arc welding resistant) |
Series Prefix Decoder:
| Prefix | Type |
|---|---|
| CG / CG5 | Stainless steel |
| CS1 / CS2 / CA2 | Tie-rod heavy duty |
| CQ2 / CM2 | Compact |
| CY3 | Rodless (magnetic) |
| MY66 | Rodless (mechanical) |
| MGP / MGPM | Guided |
| MK / CK | Clamp |
| CL / CN | Lock |
