Infineon Technologies IGBT Module TD180N16KOF

1. Main Product Series and Technology Platforms

Infineon’s IGBT modules are categorized by voltage class, package type, and chip technology to address diverse application needs:

2. Key Technology Highlights

Infineon continuously advances IGBT chip technology. The latest TRENCHSTOP™ IGBT7 technology is optimized for drive applications, achieving a better balance of power density, switching efficiency, and robustness.

• IGBT5 with .XT Interconnection Technology: This combination pairs IGBT5 chips with enhanced .XT package interconnection technology, significantly improving power cycling and thermal cycling capability, thereby extending product lifetime – crucial for reliability‑sensitive applications like wind power. PrimePACK™ modules using this technology can achieve up to 30% higher output current capability than the previous generation.

• CoolSiC™ MOSFET Modules: For high‑end industrial and automotive applications, Infineon also offers CoolSiC™ MOSFET modules based on silicon carbide. Compared to conventional silicon IGBTs, they offer much lower switching losses and can operate at higher switching frequencies, helping improve system efficiency, increase power density, or reduce system cost.

3. Application Fields and Market Position

Infineon IGBT modules are widely used in the following key areas:

• Industrial Drives: e.g., general purpose drives (GPDs), servo drives.

• Renewable Energy: solar inverters, wind turbine converters, energy storage systems (ESS).

• Automotive: traction inverters for battery electric vehicles (BEV) and hybrid electric vehicles (HEV), on‑board chargers (OBC).

• Infrastructure: uninterruptible power supplies (UPS), rail traction, power transmission.

In market terms, Infineon holds approximately 30% of the global IGBT module market, making it one of the largest suppliers worldwide. Its products are widely adopted in industrial drives, renewable energy, rail, and electric vehicles, and are considered a mainstream choice in the industry.
