Lenze Inverter EVS9332-EPV004
原价为：$17,735.14。$16,122.85当前价格为：$16,122.85。
Main Product Series – Function & Application Comparison
| Inverter Series | Power Range | Key Features | Typical Applications |
|---|---|---|---|
| EVS93xx-ES (Servo Inverter) | 0.37 kW to 90 kW | Panel-mounted, resolver/SinCos feedback, integrated mains input, electronic gearbox | Multi-axis systems, positioning control, electronic shafts |
| EVS93xx-EP (Position Controller) | 0.37 kW to 1.5 kW | Integrated position control, sequence control, cam profiler, register control | Positioning tasks, cam switching, material registration |
| EVS93xx-ESVxxx (Vector Drive) | 11 kW to 160 kW | High-power vector control, IP20 enclosure, up to 599 Hz output | Pumps, fans, conveyors, high-torque applications |
| EVS93xx-CKVxxx (Compact) | 7.5 kW | Compact enclosure, V003 firmware, built-in position control | Space-constrained automation, robotics, packaging |
Typical Applications & Industries:
✓ Multi-axis synchronization (electronic gearbox / electronic shaft) ✓ Cam profiling and switching
✓ Positioning control with sequence control ✓ Register control for printing/cutting
✓ Conveyor systems and material handling ✓ Packaging machinery
✓ Robotics and CNC machines ✓ Industrial automation OEM
Detailed Description – Lenze 9300 EVS Series Servo Inverters
1. Series Overview – The 9300 Platform
The Lenze 9300 series servo inverters (EVS prefix) are high-performance drive controllers designed for precise motor control in industrial automation. They combine the functionality of a frequency inverter, servo drive, and position controller in a single compact unit . The hardware platform is uniformly equipped with the following features:
Universal applicability – Power range from 0.37 kW to 90 kW
Integrated mains input – For single drive operations, only one component instead of two is required
Regenerative power supply modules – Enable energy-saving group applications and multi-axis setups
Flexible feedback systems – Resolvers or SinCos encoders ensure perfect adaptation to machine requirements
2. Key Technology Functions
The 9300 series integrates several advanced technology functions that traditionally required external components .
Electronic Gearbox / Electronic Shaft
Instead of mechanical vertical shafts, multiple drives can operate in exact synchronization via master frequency preselection. Proportional synchronization is easily implemented using adjustable gearing ratios .
Cam Profiler
The integrated cam profiler can store up to 8 different cam profiles, enabling profile switching during production without delays. Additional functions include electronic cam switches and marker-controlled cam start .
Register Control
For processing material lengths (printing, cutting, perforating, embossing), the integrated register control continuously realigns the angular position of draw-in rollers or printing cylinders with the print image. Drift errors are eliminated without requiring host control .
Positioning Control
Complete position controller with sequence control. Simple commissioning with minimal input values – compared to external position controllers with complicated programming languages. Automatic material correction reliably finds target positions even when initial positions have considerable tolerances .
3. Hardware Features
| Feature | Specification |
|---|---|
| Mains voltage | 320V – 528V AC (3-phase) |
| Mains frequency | 45 – 65 Hz |
| Output frequency | 0 – 599 Hz |
| Protection class | IP20 (panel-mounted) |
| Operating temperature | -10°C to +60°C |
| Feedback options | Resolver, SinCos encoder, TTL incremental encoder |
| Communication | CANopen, PROFIBUS DP, InterBus (via attachable modules) |
| Safety | Safe standstill function (STO) |
4. Power Range & Model Overview
| Model | Power (400V) | Current (8kHz) | Type | Key Feature |
|---|---|---|---|---|
| EVS9321-EP | 0.37 kW | 1.5A | Position controller | Integrated positioning |
| EVS9322-ES | 0.75 kW | 2.5A | Servo inverter | Standard servo |
| EVS9323-EP | 1.5 kW | 3.9A | Position controller | Cam profiler |
| EVS9324-ES | 3.0 kW | 7.0A | Servo inverter | High-performance |
| EVS9325-ES | 5.5 kW | — | Servo inverter | 9–10.8 kVA output |
| EVS9326-ES | 11 kW | 20.5A | Servo inverter | Industrial grade |
| EVS9327-CKV003 | 7.5 kW | — | Compact | V003 firmware |
| EVS9327-ES | 15 kW | 27A | Servo inverter | Mid-range |
| EVS9328-ES | 22 kW | 47A | Servo inverter | Up to 30kW@480V |
| EVS9329-ES | 30 kW | 84A | Servo inverter | High-power |
| EVS9330-ES | 45 kW | — | Servo inverter | High-power |
| EVS9331-ES | 55 kW | — | Servo inverter | Industrial |
| EVS9332-ES | 75-90 kW | — | Servo inverter | Highest power |
| EVS9336-ESV300 | 160 kW | — | Vector drive | High-power vector |
Selection Guide – Understanding the Naming Convention (Lenze EVS Series)
Lenze EVS part numbers encode key specifications. Understanding the coding helps rapid selection.
Example 1: EVS9322-ES
| Code | Meaning | Options |
|---|---|---|
| EVS | Product family: Servo controller / inverter | EVS = Servo/Position controller |
| 93 | Series: 9300 platform | 93 = Series 9300 |
| 22 | Power rating (kW x 10) | 21=0.37kW, 22=0.75kW, 23=1.5kW, 24=3.0kW, 25=5.5kW, 26=11kW, 27=15kW, 28=22kW, 29=30kW, 30=45kW, 31=55kW, 32=75kW |
| – | Separator | — |
| E | Mounting type | E = Panel-mounted / built-in unit |
| S | Controller type | S = Servo inverter, P = Position controller |
Example 2: EVS9327-CKV003
| Code | Meaning |
|---|---|
| EVS | Servo controller family |
| 93 | Series 9300 |
| 27 | 7.5 kW power rating |
| – | Separator |
| CKV003 | Compact version with V003 firmware (position control) |
Example 3: EVS9336-ESV300
| Code | Meaning |
|---|---|
| EVS | Servo controller family |
| 93 | Series 9300 |
| 36 | 160 kW power rating |
| -ESV300 | Vector frequency inverter variant |
Power rating decoder:
| Code digits (positions 5-6) | Power @ 400V |
|---|---|
| 21 | 0.37 kW |
| 22 | 0.75 kW |
| 23 | 1.5 kW |
| 24 | 3.0 kW |
| 25 | 5.5 kW |
| 26 | 11 kW |
| 27 | 15 kW |
| 28 | 22 kW |
| 29 | 30 kW |
| 30 | 45 kW |
| 31 | 55 kW |
| 32 | 75 kW |
| 36 | 160 kW |
Variant suffix decoder:
| Suffix | Meaning |
|---|---|
| -ES | Panel-mounted servo inverter (standard) |
| -EP | Panel-mounted position controller |
| -ESVxxx | Vector frequency inverter variant |
| -CKVxxx | Compact version with specific firmware |
